- 37 -
P
ARTS FOR THE
4857 P
ROCESS
C
ONTROLLER
(
CONTINUED
)
Part #: Description:
Pressure module parts:
A1906EP02
Pressure transducer, 0-200 psi
A1906EP05 Pressure transducer, 0-500 psi
A1906EP10 Pressure transducer, 0-1000 psi
A1906EP20 Pressure transducer, 0-2000 psi
A1906EP30 Pressure transducer, 0-3000 psi
A1906EP50 Pressure transducer, 0-5000 psi
A2599HC2 Transducer mounting body with cooling sleeve, 1/8”NPTF
A1905E Harness, pressure tranducer, 10-ft
A1905E3 Harness, pressure tranducer, 20-ft
A1905E5 Harness, pressure tranducer, 5-ft
Temperature module parts:
A472E
Thermocouple, type-J, 7-½“, grounded
A472E2 Thermocouple, type-J, 9-½“, grounded
A472E3 Thermocouple, type-J, 11-½“, grounded
A472E4 Thermocouple, type-J, 5-½“, grounded
A472E5 Thermocouple, type-J, 21-½“, grounded
A472E6 Thermocouple, type-J, 15-½“, grounded
1129E Thermocouple socket, snap-in type-J panel
A470E2 Thermocouple extension wire, type-J, 5-ft
A470E4 Thermocouple extension wire, type-J , 10-ft
A470E5 Thermocouple extension wire, type-J , 20-ft
Tachometer module parts:
A1001E
Tachometer sensor for benchtop reactor
A1001E2 Tachometer sensor for floor stand reactor
A1177E Tachometer harness, 10-ft
Cooling module parts:
A160HW3EB
Solenoid valve package, 115 V
A160HW3EE Solenoid valve package, 230 V
WARNING: For continued protection against possible
hazard, replace fuses with same type and rating of fuse.
