4857 Reactor Controllers
- 10 -
S
OFTWARE
I
NSTALLATION OF THE
4857 P
ROCESS
C
ONTROLLER
Before Software Installation
The CalGrafix software should be installed on a
PC which has not previously been used to run
software for Cal applications. The PC should
meet at least the minimum system requirements.
Minimum PC Requirements
As a general requirement, we would
recommend a minimum of Pentium 450MHz
with 256MB RAM, Windows
TM
2000/XP and
screen resolution, 1024 x 768. 100MB of
free hard drive space is more than
sufficient.
Installation Instructions:
Note: Temperature control modules have been set to park mode as a precaution against
heating before connection to a PC. Following these installation instructions will reset the
parameters for these modules to allow heating and stirring.
Do not connect the 4857 to the PC until the following installation has been completed.
CalGrafix Installation Instructions:
1. Locate the 547M CalGrafix CD and insert it into the CD drive.
2. From the CD, open the setup.exe file to run the installation program.
3. Follow on screen instructions to complete installation.
Install USB Drivers (for USB cables only)
Note: If using serial port communication, no driver installation is required.
1. Insert the 521M CD.
2. Attach USB Cable to PC. Do not connect cable to 4857 Process Controller yet.
3. The "Add new hardware" wizard should appear. Click "Next."
4. Select "Search for the best driver for your device." Click "Next."
5. The wizard will then ask the location of the driver. With the Parr 521M CD in the CD-
drive, select "CD-ROM drive" and click "Next."
6. The wizard should find the "\FTDIBUS.INF" file. If it does not find the driver, select
“specify driver location” and find the driver at: ”/installation/USB-SerialPortAdapter/BB-
Elec/USOTL4/VISTA_XP or WIN98_ME”. Click "Next."
7. The wizard should install the driver. Click "Next."
8. The wizard will also find the USB Serial Port. This should be installed in the same
manner as the previous driver. When it is finished, click "Finish."
