Martin Christ Epsilon 2-10D LSCplus - Manual (Page 31)

Freeze-dryer EPSILON 2-10D LSCplus
4 Storage and transport
Version 04/2013, Rev. 1.5 of 16/12/2014 • sb
31
Translation of the original operating manual
Pos: 78 / 200 Christ /36 0 GT -BA La bor -Pilot (S TANDARDMODULE) /04 0 La ger ung und Tr ans port /040 L age run g un d T rans por t= === == == === == == === == == === == @ 2 5\mo d_1 404 983 713 664 _68. docx @ 18 346 7 @ 1 @ 1
4 Storage and transport
Pos: 79 / 200 Christ /36 1 GT -BA La bor -Pilot (PROJEKTE )/Epsilon 2- 10D LSC plus Sta nda rd/0 40 Lage ru ng u nd Tra nspo rt/0 40- 001 0 Ab mess unge n u nd G ewicht E2 -10D @ 2 5\m od_1 404 984 892 615 _68. docx @ 18 637 9 @ 2 @ 1
4.1 Dimensions and weight
Epsilon 2-10D LSCplus
Height: 1,295 mm
Width: 1,190 mm
Depth (incl. vacuum flange connection): 850 mm
Weight: approx. 750 kg
Pos: 80 / 010 Unive rsalm odul e/Le erzeil e @ 0\mo d_1 202 116 244 500 _0.d ocx @ 114 @ @ 1
Pos: 81 / 200 Christ /36 0 GT -BA La bor -Pilot (S TANDARDMODULE) /04 0 La ger ung und Tr ans port /040 -00 20 La ger bedin gun gen @ 2 5\mo d_1 404 983 714 695 _68. docx @ 18 348 1 @ 2 @ 1
4.2 Storage conditions
In order to ensure the protection against mechanical and climatic
influences, the guidelines of the German Federal Association for Wooden
Packages, Pallets, and Export Packaging (Bundesverband Holzpackmittel,
Paletten, Exportverpackung e.V.), the so-called HPE packaging guidelines,
must be applied when packing and storing the freeze-dryer.
The storage must be:
• dust-free
• dry
• free from excessive temperature fluctuations
• free from a mechanical load.
Pos: 82 / 010 Unive rsalm odul e/Le erzeil e @ 0\mo d_1 202 116 244 500 _0.d ocx @ 114 @ @ 1
Pos: 83 / 200 Christ /36 1 GT -BA La bor -Pilot (PROJEKTE )/Epsilon 2- 10D LSC plus Sta nda rd/0 40 Lage ru ng u nd Tra nspo rt/0 40- 003 0 Tra nspo rthi nweise E2 -10D @ 2 5\m od_ 1404 984 893 417 _68. docx @ 18 639 3 @ 2 @ 1
4.3 Notes on transport
• Use suitable packaging for the transport, and if at all possible, the
original packaging.
• Install all transport safety devices (see chapter 4.5 - "Transport safety
devices").
CAUTION
The freeze-dryer Epsilon 2-10D LSCplus weighs approx. 750 kg!
CAUTION
The centre of gravity of the freeze-dryer is off-centre!
