40 Installation and Commissioning of the Unit Operating Manual Freeze Dryer BETA 1-8 LDplus / BETA 2-8 LDplus
BETA 1-8 LD
plus
BETA 2-8 LD
plus
Connection flange
Max. 5 shelves
Ø375 (unheated) Product dish
Drying vessel e.g.
injection bottle
Rubber valve
Drying chamber
Connection piece for rubber
valve to extend the drying
chamber, a max. of 18 pieces
Dying vessel e.g.
round bottom flask
Drying vessel
e.g. ampoule
Distributor
