Martin Christ Beta 2-8 LDplus User Manual
Page 12
12 General Information
Operating Manual Freeze Dryer BETA 1-8 LDplus / BETA 2-8 LDplus
BETA 1-8 LD
plus
BETA 2-8 LD
plus
Physical data (without vacuum pump):
Dimensions of the unit:
width: 780mm
height: 415mm
depth: 540mm
(incl. vacuum-flange
connection)
width: 780mm
height: 415mm
depth: 540mm
(incl. vacuum-flange
connection)
Weight:
approx.63kg
approx.78kg
Noise emissions
according to DIN 45635:
54 dB(A)
54 dB(A)
Electromagnetic
compatibility according
to EN 55011:
class B
class B
Filling quantities:
Refrigerant:
see label on the back
of the unit
see label on the back
of the unit
Connection requirements with vacuum pump 0.4KVA:
Electrical connection:
1 x 230V / 50-60 Hz
(others upon request)
1 x 230V / 50-60 Hz
(others upon request)
Power consumption:
1,3 kVA
2,0 kVA
Max. current:
4,5 A
9 A
Fuse protection:
10 A
12 A
Ambient temperature:
+10°C to +25°C
(higher temperatures
upon request)
+10°C to +25°C
(higher temperatures
upon request)
Equipment connections:
Vacuum connection:
Small flange
connection DN 25 KF
(ISO 28403,
DIN 2861)
Small flange
connection DN 25 KF
(ISO 28403,
DIN 2861)
Drain valve and
Aeration valve:
Hose nozzle DN10
(outside diameter
12mm)
Hose nozzle DN10
(outside diameter
12mm)
1)
All machine specifications (especially for temperatures, power
and capacity) refer to the nominal ambient temperature of 20°C.
