Operating Manual Freeze Dryer BETA 1-8 LDplus / BETA 2-8 LDplus General Information 11
1.3. Technical Specification
BETA 1-8 LD
plus
BETA 2-8 LD
plus
Performance data:
Ice condenser capacity
max. 8kg max. 8kg
Ice condenser
performance
1)
max. 6kg/24h max. 6kg/24h
Ice condenser
temperature
1)
approx. –55°C approx. –84°C
Shelf or product
temperature during
freezing in the ice
condenser chamber approx. –25°C approx. –50°C
Ice condenser chamber
volume approx. 11l approx. 11l
Max. shelf surface area
when drying outside the
ice condenser chamber
(process B): 5 shelves, Ø265
A
total
0.28m 2
spacing: 79mm
with accessory no.
120902
or
5 shelves, Ø360
A
total
0.51m 2
spacing: 70mm
with accessory no.
120916
5 shelves, Ø265
A
total
0.28m 2
spacing: 79mm
with accessory no.
120902
or
5 shelves, Ø360
A
total
0.51m 2
spacing: 70mm
with accessory no.
120916
Max. shelf surface area
when drying in injection
vials with sealing under
vacuum or nitrogen
atmosphere outside the
ice condenser chamber
(process B):
4 shelves, Ø250
A
total
0.18m 2
spacing: max. 50mm
with accessory no.
121011
4 shelves, Ø250
A
total
0.18m 2
spacing: max. 50mm
with accessory no.
121011
Drying in round bottom
flasks. Please note that
the max. ice condenser
capacity is 8kg
(process B):
12 pieces resp.
24 pieces
12 pieces resp.
24 pieces
