Chapter 5: Using The Cabinet
Product Service 1-800-522-7658 30
Original instructions
Information Center
The Information Center is an LCD display located on the right side wall at
eye level. When the blower is started, the words “please wait” will be
displayed, as shown in Figure 5-2. After approximately 90 seconds, the
display will switch to normal operation.
The display provides a clock, the remaining filter life, the cabinet’s current
status, inflow and downflow velocities (if equipped with the optional airflow
sensor), as shown in Figure 5-3. In the event of an alarm, the Information
Center will immediately display a context sensitive display indicating the
cause of the alarm, and possible solutions, as shown in Figure 5-4.
The display will enter sleep mode, turning itself off, one minute after the
blower is turned off or the sash is closed.
Clock
Filter Life
Status Display Window
Figure 5-2
Figure 5-3
