Front Panel Interface
27
Lake LM Series Operation Manual Rev 1.2.8
6.10.1.2 Menu Structure Overview
From the Main Menu, the following submenus are available, as shown in Figure 6-11 and described in the
following sections.
▸ MODULE (See section 6.10.2)
▸ Mixer Gain
▸ Gain
▸ Delay
▸ Polarity
▸ Limiters
▸ INPUT CONFIGURATION (See section 6.10.3)
▸ Input Router
▸ AES Termination
▸ Iso-Float
▸ Output Router
▸ FRAME (See section 6.10.4)
▸ Frame Information
▸ Frame Reset
▸ Latency Match
▸ GPIO Configuration
▸ Front Panel
▸ FRAME PRESETS (See section 6.10.6)
▸ Preset Recall
For simplicity, the following sections refer to the
buttons by their associated name on the LCD
screen. E.g. ‘Press GAIN’ equates to ‘Press the
button adjacent to the Gain label on the LCD’.
6.10.2 Module Submenu
MENU > MODULE
After selecting the Module Menu, the screen shown in Figure 6-12 is displayed. Press the illuminated button
adjacent to the required option to view or edit the associated parameters.
