Konig Electronic IP baby monitor - Manual (Page 3)

ENGLISH
3
Technical specifications
Specifications KN-BM40
Video codec MJPEG
Resolution VGA 640 x 480/QVGA 320 x 240/QQVGA 160 x 120
Frame rate 1~25 fps
Image sensor CMOS
Lens 3.0 mm
Night vision 1 Lux, 5 meter
Flash memory 8 MB
Card storage up to 32 GB SDHC (not included)
Audio 1-way (integrated microphone)
Networking protocol
IPV4, ARP, TCP, UDP, ICMP, DHCP Client, NTP Client, DNS Client,
SMTP Client, P2P Transmission
Built-in network interfaces 802.11b/g/n WLAN
Wireless security Wireless security: WEP/WPA/WPA2 wireless encryption
Wireless transmit output
power
Wireless transmit output power: 16.5 dBm for 11b,
13.5 dBm for 11g, 13.5 dBm for 11n (+/– 1.5 dBm)
Video features
Adjustable image size and quality, Time stamp and text
overlay, Flip
View angle H: 46.4°; V: 31.9°; D: 54.5°
Digital zoom Up to 4x
3A control
AGC (Auto Gain Control), AWB (Auto White Balance),
AES (Auto Electronic Shutter)
Power
External AC-to-DC switching power adapter, 100 to 240 V AC,
50/60 Hz, DC Plug Output: 5 V DC/1 A
Dimensions (W x D x H) 74 x 74 x 65 mm (excluded camera mount)
Weight 72 g (without mount)
Max. power consumption 1.9 W
Operating temperature 0 to 40 °C (32 to 104 °F)
Storage temperature -20 to 70 °C (-4 to 158 °F)
Humidity Humidity: 20% to 80% RH non-condensing
