Page 32
10.5 FAIL-SAFE Setting
The RC receiver remote control mode uncontrolled return of function, you need to
use with runaway protection function remote and the receiver.
Failsafe remote control receiver when no signal is received, output a default set
of rudder. Various models of remote control set runaway protection have said, the
reference to the remote control manual.
Return channel CH6 need to set connected to SW2 is out of control out of control
protection switch to the status of the return. Aileron, elevator, rudder channel is set to
loose rod status, throttle setting have two situation
(1) If connect the airspeed sensor to the FY-41AP Lite controller, the throttle don‘t
need setting, the controller will output a proper controlled quantity according to the target
speed.
(2) If you are not use the airspeed sensor ,the throttle need to set to cruise throttle
position.
If debugging balanced mode have been done well, the following steps will show you
the setting runaway protection (Take the Futaba remote control T10CHG for example).
Settings, turn off the power to the aircraft, to avoid setting the motor starts.
First enter the remote control setup menu to find the set of "F / S"; into the F / S menu,
the lever into the neutral position, rudder trimming to maintain the status adjusted, the
throttle lever to the cruise throttle position(apply to situation (2)), the CH6 cut to return
mode. Then in all open channel F/ S, and often set by the "PUSH" button, set successfully
as shown.
After setting the aircraft, powered off the remote control and check whether it can
successfully entered the return mode. Pay attention to safety, to prevent the Failsafe
motor rotation, met items cause damage.
10.6 Fixed Altitude & Heading Lock Mode Instruction
Fixed altitude & Heading lock Mode – This mode maintains aircraft flight course &
holds the altitude on activation. By using GPS data, the system automatically corrects
flight course deviation & maintains straight-line flight.
