FeiYu Tech FY-41AP Lite - Manual (Page 26)

Guilin Feiyu Electronic Technology Co., Ltd.
Guilin Feiyu Electronic Technology Co., Ltd http://www.feiyu-tech.com [email protected]
Page 24
( 3 ) Rudder
(Check in "Auto Balance Mode" )
CLOCKWISE rotate your plane, the rudder should move to the Left.
COUNTERCLOCKWISE rotation, the rudder should move to the Right
If the servo movement is incorrect, you need to reverse the automated servo
movement, please select “RUD REV”.
Turn left
Rudder moves to the right
Turn right
Rudder moves to the left
( 4 ) Throttle
Push throttle from light to strong, if the servo display chart of the remote control is
display (-100 to 100) please don ‘t select the‖ throttle reverse‖ option in the rudder reverse,
if display chart display from big to small (100 to -100), please select the
‖ throttle reverse‖
option in the rudder reverse.
In general, use ESC for throttle controlling can be choose the default settings (NOR),
without ESC reverse setting.
Step Four: Basic sensitivity setting for automatic control
We suggest that the first flight should be in default value, then adjust the value
according to the actual flight.
Adjustment principle: check the gain of stability whether it is normal in the "Auto
Balance Mode ―.
Control aircraft in roll, then loosen the rocker, observe that whether the plane can be
automatic recovery level. Control aircraft in pitch, then loosen the rocker, observe that
whether the plane can be automatic recovery level. If the automatic recovery control can
not strong enough, you can tone the gain of stability. If the pitch and roll swings back and
forth, it means the parameters is too big, it need decrease to a small amount.
The greater gain of RUD the weaker effect of the servo when in making a turn .
