Page 13
(1) Through SW1:
On SW1, switch ABM to Deactivated Mode 6 times, time interval has to be less than 3
seconds as follows:
ABM→ Deactivated Mode → ABM → Deactivated Mode → ABM → Deactivated
Mode → ABM → Deactivated Mode → ABM → Deactivated Mode → ABM → Deactivated
Mode.
After doing this operation, the LED will bright white light about 1S.Wait for the
LED go out, then the gyro initialization finish.
(2) Through OSD video overlay menu ―INIT GYRO‖ option.
(3) Through the ― FYGCS 5.11 for 41& DOS ‖setting software ―Initialize the gyro‖
button which in the ―Autopilot Configuration Wizard‖ option.
(Note: Making gyro initialization via the OSD menu and the ―FYGCS 5.11 for
41&DOS ‖ setting software, won't appear the phenomenon of the LED bright white light.)
7.7 FY-41AP Lite Indicator Light Instruction
FY-41AP Lite with three colors LED which can send out red,
blue, green light. Also yellow, white, purple and other colors light
t hrough the combination.
Operators can know the FY-41AP Lite ‘s operating mode by judging the different
colors which the LED sends out and the flash frequency. Green light flash means GPS
location fixed, red and blue light indicate FY-41AP Lite working mode.
