Page 28
Step Seven: Record attitude
The default attitude angle is ―0‖ (zero). After finish the installation, the aircraft place
to the level flight attitude, then record the attitude. This function is used to eliminate any
installation deviation from the default.
When record the level flight attitude on the ground via toggle switch, it will initialize the
gyro at the same time, so ensure the aircraft absolute static. Please according to following
steps to complete the recording.
1 ) The aircraft put on the ground in level flight attitude, keep static.
2 ) Under the RC mode, the remote control rocker position in the middle, the throttle
rocker position to the lowest ,adjust rudder surface to leveling.
3 ) Switch to the ABM mode ,then switch from ABM mode to the RC mode 8 times,
the LED light from white to green, and then the aileron rudder surface will execute an
operation that a tilt and then back to the flat to prompt the success of the recording.
―ABM→RC→ABM→RC→ABM→RC→ABM→RC→ABM→RC→ABM→RC→ABM→RC
→ABM→RC‖.
This operation will finish the recording and save permanent automatically.
Note: The first flight or after upgrading firmware, you need to record level flight
attitude. But don’t need to record before every flight.
9. FY-41AP Lite First Flight Test Checklist
Adjustment of the aircraft
Fine-tuning adjustment after take-off in balanced mode, leveling the aircraft the
throttle placed into cruise throttle position. If the manual mode level flight trimming,
and the level of the balanced mode fly to fine-tune a lot of difference, it is recommended
that record level flight attitude again. If the manual mode leveling switch to balance mode,
the aircraft bow, you need to elevate the head record level flight attitude, and vice versa
pad low head re-recorded.
Take off
Take off in manual mode. If you are confident, after completing the basic check, you
can take off in ABM, This is more suitable for the remote control skills are not enough
skilled operator.
Other settings can temporarily use the default settings, the following can be
flown for the first time. After each set and do not forget the " Save parameters "
