QualityAssurer 805 45
A Technical Specifications
QualityAssurer - QA-805
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
SPECIFICATIONS
QA-813 QA-805 QA-604
Platform 13 slots, rack-mounted 5 slots, rack-mounted 4 slots, rack-mounted or desktop
Hot-swappable modules Up to 6 W 2 CM-10GbE or
13 W 2 CM-10GbE-Lite
Up to 2 W 2 CM-10GbE or
5 W 2 CM-10GbE-Lite
Up to 4 SCM-GbE or 2 MCM-GbE
(or MCM-GbE-Lite)
Reset Per platform, per interface or per port
(hardware or software) Per platform, per interface or per port
(hardware or software) Per platform, per interface or per port
(hardware or software)
Interfaces USB, DP, Ethernet (management) USB, DP, Ethernet (management) USB (2), VGA, Ethernet (management)
Operating system Linux Linux Solaris
Processor and memories AMC Core i7 2.53 GHz, 8 GB RAM,
500 GB hard disk AMC Core i7 2.53 GHz, 8 GB RAM,
500 GB hard disk Intel Core 2 Duo, 2 GHz, 2 GB RAM (min),
120 GB hard disk (min)
Remote control Standard Windows applications
such as VNC and Exceed Standard Windows applications
such as VNC and Exceed Standard Windows applications
such as VNC and Exceed
Size (H x W x D)
577 mm x 443 mm x 434 mm
(22.72 in x 17.44 in x 17.09 in) 265.90 mm x 482.60 mm x 388.45 mm
(10.47 in x 19 in x 15.29 in) 101 mm x 483 mm x 362 mm
(4 in x 19 in x 14 ¼ in)
Weight 29 kg (64 lb) 25.50 kg (56 lb) 5.5 kg (12.1 lb)
Power supply Recommended rectifier:
Input: 90-277 V, 47-63 Hz, 25 A x 4
Output: 60 V — Max. 17200 W 850 W, 90 to 264 V input,
single plus 5 VSB output 100 to 240 V, 50/60 H
