Introduction
4
QA-805 and W2CM Interface Module
Physical Description of QA-805 Unit
Physical Description of QA-805 Unit
Chassis Front Panel
The following is a picture of the front of the QA-805 rack-mount model.
1. Right Fan Tray [FT1]
2. Left Fan Tray [FT2]
3. Power supplies cover and air filter holder
4. Control Board/Slot 2 [SHMC2] (not populated)
5. Control Board/Slot 1 [SHMC1] (Shelf Manager)
6. Backplane
7. ESD (Electrostatic Discharge) Wrist Strap Terminal (Banana Jack)
8. Rack ears for mounting in 19” rack
9. Power supply unit/slot 1
