W2CM-10Gb Ethernet Interface Series
QualityAssurer 805 31
10 G LAN/WAN Optical Interfaces (SFP+)
10 G LAN/WAN Optical Interfaces (SFP+)
Two Class 1 Laser SFP+ interfaces are available on the faceplate. On the
host side, these SFP+ interfaces are connected directly to the LIM FPGA.
The following optical SFP+ from Finisar, are supported:
Optical SFP+ with LC Connector
EXFO
Product #
Transceivers
(Finisar)
Output
Power
(dBm)
Rx Sensitivity
(dBm)
SFP+ Specs
FTB-8690 FTLX8571D3BCL
Multi-rate
9.95-10.3 Gbit/s
10GBASE-SR/SW
MIN = -5
MAX = -1
@ 10.3 Gbit/s
MIN = -11.1
MAX = 0.5
850 nm
300 m OM3
FTB-8691 FTLX1471D3BCL
Multi-rate
9.95-10.5 Gbit/s
10GBASE-LR/LW
10GFC
MIN = -8.2
MAX=+0.5
@ 10.3 Gbit/s
MIN = -12.6
MAX= 0.5
1310 nm
10 km SMF
FTB-8692 FTLX1671D3BCL
Multi-rate
9.95-10.3 Gbit/s
10GBASE-ER/EW
MIN = -4.7
MAX =+4.0
@ 10 Gbit/s
MIN = -14.1
MAX = -1.0
1550 nm
40 km SMF
