EXFO QA-805 User Manual
Page 40
W2CM-10Gb Ethernet Interface Series
32
QA-805 and W2CM Interface Module
10 G LAN/WAN Optical Interfaces (SFP+)
LED definition for 10 G optical SFP+:
LED#
Label
Color
Definition
1
Activity
Off
Idle
Green
Unidirectional Activity RX
Yellow
Bidirectional Activity
Red
Unidirectional Activity TX
LED#
Label
Color
Definition
2
Laser On/Signal
Off
Laser off
Green
Laser on - signal, with link
Yellow
Laser on - signal, no link
Red
Laser on - no signal
