Power, Battery status, Power schemes – EXFO MaxTester MAX-630 User Manual
Page 25
Setting Up the MAX-630
VDSL2/ADSL2+ Multi-play Test Set
19
Power
Power
Battery Status
The BATTERY Status pane indicates the current
power level for the battery.
Note: The battery level might not display after a system
upgrade but will become available again after the
next full charge.
Power Schemes
You can set your unit to automatically switch to suspend mode
independently for the battery or DC power modes. This is useful for
example if you want to save battery power but do not want to be hindered
by unwanted switches between modes when using DC power.
Power off completely shuts down the unit’s
power.
Power suspend puts the unit in sleep mode; you
can wake up the system by pressing .
DC IN/BATTERY Idle timeout allows you to set
the time duration for the unit to idle (no keys
pressed or test being run) before turning off the
LCD.
DC IN/BATTERY suspend timeout allows you to
set the time duration for the unit to enter sleep
mode.
