VDSL2/ADSL2+ Multi-play Test Set 121
A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
DSL SPECIFICATIONS
DSL chipset Broadcom
Standards compliance ADSL1/2/2+ ITU-T G.992.5 (ADSL2+ including Annex A, B, J, M)
ITU-T G.992.3 (ADSL2 including Annex A, B, J, L)
ITU-T G.992.1 (G.DMT including Annex A, B)
ITU-T G.994.1
ATIS/ANSI T1.413 Issue 2
IEEE 802.3ah (PTM)
ITU-T G.998.1, 2 (ATM, Ethernet bonding)
ITU-T G.998.4 (G.INP)
DT 1 TR 112 U-R2
VDSL2 ITU-T G.993.2 Annex A, B, Y
Profiles: 8a/b/c/d, 12a/b, 17a, 30a
Band Plan: 997, 998, US0
IEEE 802.3ah (PTM)
ITU-T G.998.2 (Ethernet bonding)
ITU-T G.998.4 (G.INP)
ITU-T G.993.5 (G.Vector)
DT 1 TR 112 U-R2 (U-RV2)
DSL parameters Maximum attainable bit rates
Actual achieved bit rates
Actual bonded achieved rates
Latency modes: fast, interleaved
Data modes: ATM, PTM
Capacity (%)
Signal-to-noise ratio (SNR) margin
Output power
Attenuation
Bits/bin
Attenuation/bin (Hlog/bin)
QLN/bin
SNR/bin
Vendor code, revision
Interleave depth
Interleave delay
Trellis coding
Bit swapping
INP
Nitro
PhyR, G.INP state, performance counters
Vectoring state, performance counters
Modes: PTM, ATM, Nitro
LOS, FEC, CRC, HEC
LATN per band
SATN per band
EWL
KL0
