Technical Specifications
VDSL2/ADSL2+ Multi-play Test Set 123
GENERAL SPECIFICATIONS
Display TFT LCD with backlight
152 mm (6 in) diagonal
800 x 480 resolution, WVGA
Test connections RJ11 for ADSL2+/VDSL2
RJ45 for Ethernet 10/100 WAN
RJ45 for Ethernet 10/100 LAN
Results storage 1.2 GB internal memory
Temperature
operating
storage 0 °C to 40 °C (32 °F to 104 °F)
–20 °C to 60 °C (–4 °F to 140 °F)
Relative humidity 5 % to 95 %, non-condensing
Shock 1 m (39 in) drop per GR-196-CORE
Altitude 3000 m (9842 ft)
Input power 9-24 VDC, 2 A, 15 W via 90-220 VAC adapter or 12 V vehicle adapter
Battery Internal rechargeable lithium polymer, with battery-state and level indications, adjustable auto-power down
Safety CE and CSA marked
Size (H x W x D) 254 mm x 124 mm x 62 mm (10 in x 4 7 /
8
in x 2 7 /
16
in)
Weight (with battery) 1.5 kg (3.3 lb)
Water/dust ingress IP54 compliant
Self-test Routine on power-up
Connectivity Two USB 2.0 client ports
One USB Type B host port
Languages English, French, Spanish
