Working with Your Unit
Compact Modular Platform 89
Taking Screen Captures
To take only one screen capture:
1. From the unit's keypad, press the
button.
2. Tap the button.
The screen capture is automatically taken (a sound and visual effect typical
of a camera taking a picture indicate that the capture is complete).
Note: If a keyboard is connected to your unit, you can also press the
PRINT SCREEN key.
To take several screen captures:
1. If you have configured one of the shortcut buttons to automatically
display the virtual keyboard, press the appropriate button.
OR
From Compact Toolbox, tap the on-screen keyboard icon on the
lower-right part of the screen (under the clock).
2. Once the on-screen keyboard is displayed, tap the button.
3. From the floating toolbar, tap the button.
The screen capture is automatically taken (a sound and visual effect typical
of a camera taking a pictureindicate that the capture is complete).
