EXFO FTB-200 v2 Compact Modular Platform User Manual
Page 15
Introducing the FTB-200 v2 Compact Modular Platform
Compact Modular Platform
5
LED Panel Description
Red, blinking
Laser status LED
At least one module emits an optical signal.
Off
No modules emit signal.
Green
Result status from application currently displayed.
Pass (result does not exceed the defined threshold).
Green, blinking
Result statuses from two or more applications.
Pass (no results exceed the defined threshold).
Red
Result status from application currently displayed.
Fail (result exceeds the defined threshold).
Red, blinking
Result statuses from two or more applications.
Fail (all results exceed the defined threshold).
OR
Mixed statuses (some are Pass and some are Fail).
LED
Status
Meaning
