Introducing the FTB-200 v2 Compact Modular Platform
Compact Modular Platform
7
Ports
Ports
Your unit is equipped with several communication ports (for probe, mouse,
keyboard, hub, etc.). It can also be equipped with internal Wi-Fi and
Bluetooth devices for wireless information transfer. These two devices are
optional.
There are two USB 2.0 host ports located on the left panel of the unit.
All the other ports are located on the right panel of the unit:
8-pin (mini-DIN) connector to connect the fiber inspection probe.
USB 2.0 host port (type A connector)
to connect USB memory
drives, keyboards, mouse devices, etc.
RJ-45 (10/100/1000 Base-T) port to connect your unit to an Ethernet
network.
Headset/microphone port (for 2.5 mm connector).
