EXFO FTB-200 v2 Compact Modular Platform User Manual
Page 205
Troubleshooting
Compact Modular Platform
195
Restoring Your Unit to Normal Operation
To retrieve data from the D drive:
1. Turn on the FTB-200 v2.
2. While the system is displaying the boot menu (3 seconds), press
from the unit’s keypad to select the Maintenance and
recovery mode.
OR
Press the ARROW DOWN key on the keyboard (if you have connected
one).
3. Press the unit’s knob or ENTER on your keyboard to confirm your
choice.
Note: The touchscreen becomes effective at this point.
4. From the main window, select Backup data and configuration files
to USB flash drive, then tap Next.
