Storage Devices, Audio & Mouse
2 - 2 Hard Disk Drive
2
Hard Disk Drive
The hard disk drive(s) is(are) used to store your data in the computer. The hard
disk(s) can be taken out to accommodate other 2.5" serial (SATA) hard disk drives
with a height of 9.5 mm. The hard disk(s) is(are) accessible after removing the com-
ponent bay cover from the bottom of your computer as seen below.
Further details on removing and inserting the hard disk are available in “Upgrading
the Hard Disk Drive(s)” on page 6 - 9 .

Power Safety
Before attempting to ac-
cess any of the internal
components of your
computer please ensure
that the machine is not
connected to the AC
power, and that the ma-
chine is turned off. Also
ensure that all peripher-
al cables, including
phone lines, are discon-
nected from the comput-
er.
Figure 2 - 1
Hard Disk Location
Model A Model B
Model A (with 1 * HDD installed) Model B (with 2 * HDDs installed)
