Upgrading The Computer
Upgrading the Optical (CD/DVD) Device 6 - 15
6
Removing the Optical Device for Model A Computers
1. Turn off the computer, and turn it over and remove the battery and component bay
cover (see pages
6 - 4 & 6 - 6 ).
2. Remove the screw at point , and use a screwdriver to carefully push out the
optical device at point .
3. Reverse the process to install the new device.
4. Replace the component bay cover (see page 6 - 8 ).
Figure 6 - 9
Removing the
Optical Device
(Model A
Computers)
1
2
1
2
