System Map: Right & Rear Views 1 - 17
Quick Start Guide
1
System Map: Right & Rear Views
Figure 1 - 6
Right & Rear Views
1. Headphone-Out
Jack
2. Microphone-In
Jack
3. S/PDIF-Out Jack
4. USB 2.0 Port
5. Optical Device
Drive Bay
6. Security Lock Slot
7. Battery
1 2
5
3 4

CD/DVD Emergency Eject
If you need to manually eject a CD/DVD (e.g. due to an unexpected power interruption)
you may push the end of a straightened paper clip into the emergency eject hole. Do not
use a sharpened pencil or any object that may break and become lodged in the hole.
Don’t try to remove a floppy disk/CD/DVD while the system is accessing it. This may
cause the system to “crash”.
Disk Eject Warning
Don’t try to eject a CD/DVD while the system is accessing it. This may cause the system
to “crash”. Stop the disk first then eject it, or press the stop button twice.
6 7
