1 - 12 System Map: Left View

Quick Start Guide

1

System Map: Left View

Figure 1 - 5

Left View

1.

RJ-45 LAN Jack

2.

External Monitor
Port

3.

HDMI-Out Port

4.

Headphone-Out
Jack

5.

Microphone-In
Jack

6.

Vent/Fan Intake

7.

2 * USB 3.0 Ports

2

5

4

1

3

7

6

USB 3.0 Ports

USB 3.0 ports are denoted by their blue color; USB 2.0 ports are colored black. Note that the USB
3.0 port requires a driver installation (see

“USB 3.0” on page 4 - 7

), does not support wake on

USB and is not operational under DOS.

Optical Device Drives

To install applications and drivers etc. you will need to attach an external optical CD/DVD device to the
USB ports.
