Upgrading The Computer
Replacing the Component Bay Cover 6 - 7
6
Replacing the Component Bay Cover
1. Make sure latch is in the unlocked (i.e. slide to the left towards the unlocked
symbol) position (otherwise the cover cannot be properly reinserted).
2. Press the cover firmly down with you hand, as illustrated, to insure the cover is in
place.
3. Align the markers on the case and cover first, and then slide the cover in the
direction of arrow until it clicks into place.
Figure 6 - 4
Component Bay
Cover Insertion
1
2
3
2
2 2
1
3
