Upgrading The Computer
6 - 10 Upgrading the Hard Disk Drive
6
4. When the connector can be viewed, lift the assembly up in the direction of arrow
to remove the HDD assembly from the bay.
5. Remove the screws & , bracket and adhesive cover .
6. Reverse the process to install a new disk and do not forget to replace the screws
and cover.

Hard Disk Handling
Do not press down on the
center off the hard disk as
this area houses the hard
disk drive motor.
Figure 6 - 6
Hard Disk Assembly
Removal
4
5 6 7 8
5
6
7
8
4
