10 - System Map: Front View with LCD Panel Open - Models B & D
Concise User’s Guide
English
System Map: Front View with LCD Panel
Open - Models B & D
Figure 3
Front View with LCD
Panel Open
(Models B & D)
1. Built-In PC Camera
(Optional)
2. LCD
3. Speakers
4. Power Button
5. Hot-Key Buttons
6. Keyboard
7. Built-In Microphone
8. Touchpad & Buttons
9. Fingerprint Module
(Optional)
10. LED Indicators
TouchPad button
(valid operation area)
8
Wireless Device
Operation Aboard Aircraft
The use of any portable elec-
tronic transmission devices
aboard aircraft is usually prohib-
ited. Make sure the wireless
modules are OFF if you are
using the computer aboard
aircraft.
Use the key combinations to
toggle power to the 3.5G/
WLAN/Bluetooth modules,
and check the LED indicator
icon to see if the modules are
powered on or not (see
Table 2
on page 11 / Table 4 on
page 13 ).
