Ditch Witch RT55 - Manual (Page 155)

Specifications - 154
RT55 T4i Operator’s Manual
RT55 Tractor
Backfill Blade (wth 35 x 19-16.1 tire) U.S. Metric
Blade width 72 in 1.8 m
Blade height 14 in 355 mm
Lift height above ground 19 in 480 mm
Blade drop below ground 12 in 305 mm
Maximum swing angle (left/right) 30° 30°
Tilt angle (up/down) 16° 16°
Power U.S. Metric
Engine: Deutz D2011L04O diesel
Cooling medium: liquid (oil cooled)
Injection: direct
Aspiration: natural
Number of cylinders: 4
Displacement
220 in
3 3.6 L
Bore 3.8 in 97 mm
Stroke 5.0 in 127 mm
Engine manufacturer’s gross power rating (SAE J1995) 62 hp 46 kW
Estimated net power rating (SAE J1349) 59 hp 44 kW
Rated speed 2600 rpm 2600 rpm
Maximum engine tilt angles*
Longitudinal 25° 25°
Lateral 25° 25°
*Exceeding these operating angles will cause engine damage. This DOES NOT IMPLY machine is
stable to maximum angle of safe engine operation.
