Specifications - 152
RT55 T4i Operator’s Manual
RT55 Tractor
L
3 Wheelbase 60 in 1.5 m
L
4 Rear axle center to rear attachment mounting holes 14.7 in 373 mm
W
Width 76 in 1.9 m
W
2 Tread 58 in 1.5 m
General
Ditch Witch model RT55 tractor, 4-wheel drive, rigid frame, hydrostatic ground drive through rubber
tires, 4-wheel steering, hydrostatic attachment drive, riding unit
Operation (with 31 x 15.50-15 tire) U.S. Metric
Forward speeds
Low 1.7 mph 2.7 km/h
High 5.5 mph 8.9 km/h
Reverse speeds
Low 1.1 mph 2.7 km/h
High 3.4 mph 5.5 km/h
Vehicle clearance circle (SAE) wall to wall with backfill blade
Front steer only 33.5 ft 10.2 m
Coordinated steer 21.5 ft 6.5 m
Ground clearance 10 in 254 mm
Basic unit weight without front cast weight 5610 lb 2545 kg
Maximum allowable tractor weight 12,000 lb 5445 kg
Front counterweight 1915 lb 870 kg
