Ditch Witch P80 - Manual (Page 65)

Specifications - 64
P80/PP25 Operator’s Manual
PP25
CMW
Specifications are called out according to SAE recommended practices where indicated. Specifications are
general and subject to change without notice. If exact measurements are required, equipment should be
weighed and measured. Due to selected options, delivered equipment may not necessarily match that
shown.
Power U.S. Metric
Engine: Honda GX690, EPA Phase III
Fuel: gasoline
Cooling medium: air
Cylinders: 2
Displacement
42 in
3
688 cm
3
Bore 3.03 in 77 mm
Stroke 2.83 in 72 mm
Power
manufacturer’s gross power rating (per SAE J1995) 22.2 hp 16.6 kW
rated speed 3600 rpm 3600 rpm
Hydraulic System U.S. Metric
Pump
Flow capacity @ 3200 rpm 11.7 gpm 44.3 L/min
Maximum pressure 2500 psi 172 bar
Filtration (nominal) 10 micron 10 micron
Fluid Capacities U.S. Metric
Fuel tank 9.5 gal 36 L
Hydraulic reservoir 20 gal 76 L
Engine oil, including filter 2.1 qt 1.9 L
Battery
12V, negative ground, SAE cold crank rating @ 0°F (-18°C), 525 amps.
SAE reserve capacity rating, 85 min
Noise Levels
Exterior sound power per ISO 6394 is < or = to 108 dBA per ISO 6394.
