16. Block Diagram
This diagram shows how the main components in GalacTix are connected. The Computer Shelf and
Projector plug into the Power Splitter. The A/C Harness powers the Projector PCB while the game is
on, but the Battery Pack powers the Projector PCB and Projector Fans after the game is shut off. The
batteries run the fans for 3-5 minutes after power down, which helps cool the projector and extend the
life of the lamp.
See Page 9 for more information on the Rechargeable Battery Pack and Projector PCB.
WALL
OUTLET
INLET
PLATE
POWER
SWITCH
VGA
USB
PROJECTOR
MINI DIN 8
I/O
BOARD
USB
STEREO
CABLE
POWER
SPLITTER
A/C
HARNESS
PROJECTOR
PCB
COMPUTER
SHELF
BATTERY
PACK
PROJECTOR
FANS
