18
Switches – Select this option to test the
functionality of the switches.
Video – Select this option to test that the
monitor is working properly.
Audio – Select this option to test that the
speakers are working correctly.
Motherboard – This gives information about the
hardware in the computer as well as software
version numbers
Click Coin Meter – This sends a pulse to the
Coin Meter. Use this to quickly test that the
Coin Meter is working.
Click Ticket Meter - This sends a pulse to the
Ticket Meter. Use this to quickly test that the
Ticket Meter is working.
Switch Test
Lamp Test
Diagnostics
GALACTIX
CHICAGO GAMING
V 0.9.7
MARCH 3, 2010
GALACTIX
CHICAGO GAMING
V 0.9.7
MARCH 3, 2010
SWITCH TEST
COIN 1
COIN 2
COIN 3
COIN 4
COIN 5
COIN 6
TICKET 1
TICKET 2
TICKET 3
TICKET 4
TICKET 5
TICKET 6
SERVICE
MENU
UP
DOWN
FIRE 1
FIRE 2
FIRE 3
FIRE 4
FIRE 5
FIRE 6
PRESS MENU AND SERVICE TO EXIT
GALACTIX
CHICAGO GAMING
V 0.9.7
MARCH 3, 2010
LAMP TEST
IO BOARD REVISION: 01
ALL LAMPS FLASHING
PRESS ANY BUTTON
FOR INDIVIDUAL LAMP TEST
PRESS MENU AND SERVICE TO EXIT
GALACTIX
CHICAGO GAMING
V 0.9.7
MARCH 3, 2010
LAMP TEST
IO BOARD REVISION: 01
PRESS MENU FOR CHASE 1
PRESS SERVICE FOR CHASE 2
PRESS UP FOR CHASE 3
PRESS DOWN FOR CHASE 4
PRESS FIRE BUTTONS TO
TEST FIRE LAMPS
(IF INSTALLED)
PRESS MENU AND SERVICE TO EXIT
Lamp Test – Use the Lamp Test to check the
lights in the fire buttons and make sure the
Chase Lights in the Marquee and Nose Cone
are working properly
DIAGNOSTICS
SWITCHES
LAMPS
VIDEO
AUDIO
MOTHERBOARD
CLICK COIN METER
CLICK TICKET METER
RETURN TO MAIN MENU
Switches – Activating a switch will cause its
name to light up on the screen. The Coin
switches are activated when the comparator
recognizes a coin. If a coin mech is always
on, check that the switch on the back is set to
N.O. The Ticket switches are active when the
ticket mechanism sees a notch in the tickets.
