Touch Pad Control
Ducted Evaporative Air Conditioning
TEK600 Series Control Page 13
THERMOSTAT MODE
Step 1 Press the ON / OFF button to turn the unit on.
Step 2 The Appliance will be in COOL mode.
Step 3 To select the THERM (Thermostat) mode touch
anywhere in the MODE outline.
STEP 4 Press THERM and the selected icon will stop
flashing. The remaining icons will flash 3 more
times and then disappear.
Step 5 To adjust the comfort level use the .
Increase the graphics scale for more cooling, decrease
for less cooling.
Note: The comfort level is individual to each situation and location. Some trial and error may be required to set the
graphic scale to your desired comfort level; a good starting point is to have the scale set at approximately the half
way mark. Once the unit has been set, the fan speed and pump are controlled automatically. The unit can be left
and will cycle on and off to keep the area being cooled to the set comfort level.
PROGRAM MODE
Step 1 Press the ON / OFF button to turn the unit
on.
Step 2 The Appliance will be in cool mode.
Step 3 To select the PRGM (Program) mode touch
anywhere in the MODE outline.
Step 4 Press PGRM. The selected icon will stop
flashing and the remaining icons will flash 3
more times and then disappear. In addition
the programmed mode of operation icon will
also be displayed when the program calls for
it.
This function will only enable program mode. To setup the program parameters refer to the section
“Operating the Touch Pad – SETUP” to edit the settings.
Program Mode will only operate for a 24hour period from activation and then the product will
cease to function until the unit is restarted.
