2.8 Power Input (Phoenix type)
GOT5100T-834 equips with a phoenix type power connector. It adopts 9VDC to 36VDC.
Please follow the signs on power connector to connect DC power source.
+: Power positive
G: Safety ground
－:Power negative
NOTE
The safety ground must be connected to ensure the unit working appropriately.
