GOT5100T-834 User’s Manual
Hardware and Installation 31
2.6 DRAM Installation
The GOT5100T-834 provides one 204-pin DDR3L SODIMM socket that support system
memory up to 8GB. Please follow steps below to install the memory modules:
Step 1
Open the back cover and find out the DIMM socket on main board(SBC87834).
Step 2 Insert the DRAM to the DIMM socket, and then push it down firmly until it is
clipped by the socket.
