GOT5100T-834 User’s Manual
Hardware and Installation 21
Audio Lin In connector: CN15
CN15 Pin Assignment
Pin Description
1 LINE IN L
2 GND
5 LIN IN R
Power lamp connector: CN16
CN16 Pin Assignment
Pin Description Pin Description
1 Power (+5V) 2 GND
Power button connector: CN17
CN17 Pin Assignment
Pin Description Pin Description
1 Power Button 2 GND
