2.2.1 Jumper Settings
Making the proper jumper settings configure the SBC87834 to match the needs of your
application.
The following table shows the default jumper settings for the onboard devices.
Jumper ★ Default Setting Jumper Setting
JP1
★ Panel backlight control PWM mode
Panel backlight control DC mode
Short 1-2
Short 3-4
JP2
Touch Controller 4,8 WIRE
★ Touch Controller 5 WIRE
Short 1-2
Short 2-3
JP4
★ LVDS Panel Power : 3.3V
LVDS Panel Power : 5V
Short 1-2
Short 2-3
JP5
Touch OFF
★ Touch ON
Short 1-2
Short 2-3
JP6
★ PCIe device
mSATA device Short 1-2
Short 2-3
JP7
AT mode
★ ATX mode
Short 1-2
Short 2-3
JP8
★ Normal
Clear CMOS
Short 1-2
Short 2-3
JP11
COM3_5VSB
★ COM3_5V
Short 1-2
Short 2-3
JP12
★ COM1 normal mode
COM1 pin1 with power :+5V
COM1 pin9 with power :+12V
Short 3-5,4-6
Short 1-3,4-6
Shot 3-5,2-4
JP13
★ COM2 normal mode
COM2 pin1 with power :+5V
COM2 pin9 with power :+12V
Short 3-5,4-6
Short 1-3,4-6
Shot 3-5,2-4
JP14
★ COM3 normal mode
COM3 pin1 with power :+5V
COM3 pin9 with power :+12V
Short 3-5,4-6
Short 1-3,4-6
Shot 3-5,2-4
JP15
★ COM4 normal mode
COM4 pin1 with power :+5V
COM4 pin9 with power :+12V
Short 3-5,4-6
Short 1-3,4-6
Shot 3-5,2-4
