ERX-Q77 User’s Manual
ERX-Q77 User’s Manual 55
3.3 Using Setup
The keys in the legend bar allow you to navigate through the various setup menus
Key(s) Function Description
→←
Select Screen
↑↓
Select Item
Enter Select
+ - Change Opt.
F1 General Help
F2 Previous Values
F3 Optimal Defaults
F4 Save and Exit
ESC Exit
3.3.1 List Box
This box appears only in the opening screen. The box displays an initial list of configurable
items in the menu you selected.
3.3.2 Sub-menu
Note that a right pointer symbol appears to the left of certain fields. This pointer
indicates that you can display a sub-menu from this field. A sub-menu contains additional
options for a field parameter. To display a sub-menu, move the highlight to the field and press
. The sub-menu appears. Use the legend keys to enter values and move from field to
field within a sub-menu as you would within a menu. Use the key to return to the main
menu.
Take some time to familiarize yourself with the legend keys and their corresponding functions.
Practice navigating through the various menus and submenus. If you accidentally make
unwanted changes to any of the fields, press to load the optimal default values. While
moving around through the Setup program, note that explanations appear in the Item Specific
Help window located to the right of each menu. This window displays the help text for the
currently highlighted field.
