ERX-Q77 User’s Manual
22 ERX-Q77 User’s Manual
2.4.1 Internal Connectors
Internal Connector
Label Function Note
CPU_FAN CPU Fan Connector 4 x 1 wafer, pitch 2.54mm P43
SYS_FAN System Fan Connector 4 x 1 wafer, pitch 2.54mm P43
CHA_FAN Chassis Fan Connector 4 x 1 wafer, pitch 2.54mm P43
F_PANEL Intel Front Panel connector 5 x 2 header, pitch 2.54mm P44
EATXPWR1 ATX power connectors 12 x 2 wafer P45
ATX12V1 12V ATX power connectors 2 x 2 wafer P45
COM3 ~ 5 Serial Port Connector 5 x 2 header, pitch 2.54mm P46
DIO1 Digital I/O Connector 6 x 2 header, pitch 2.54mm P46
FPAUD1 Audio Mic.-In & Line-Out Connector 5 x 2 header, pitch 2.54mm P47
SPDIF_O Digital Audio connector 4 x 1 header, pitch 2.54mm P48
JAMP1 Amplifier Connector 4 x 1 header, pitch 2.54mm P48
SATA1 ~ 6 SATA Data Connector * 6 7P Male connector P49
USB5~10 USB Connector * 6 5 x 2 header, pitch 2.54mm P50
LVDS1 LVDS Connector 20 x 2 wafer P51
JBKL1 LVDS Inverter Power Connector 5 x 1 wafer, pitch 2.00mm P51
LPT1 Print Port Connector 13 x 2 wafer, pitch 2.00mm P52
