2.8.6 LVDS Backlight power selection (JBKLVOL1)
This jumper allows you to select LVDS backlight power type +3.3V / +5V
+3.3V (Default)
1
+5V
1
2.8.7 LVDS Backlight control mode (JBKL2)
This jumper allows you to select LVDS backlight control mode
PWM (Default)
1
Linear
1
