Removing a dimm – Avalue ERX-Q77 User Manual
Page 34
ERX-Q77
User’s Manual
34 ERX-Q77
User’s Manual
2.6.4
Removing a DIMM
1.
Simultaneously press the retaining clips downward to unlock the DIMM.
2.
Remove the DIMM from the socket.
Support the DIMM lightly with your fingers when pressing the retaining
clips. The DIMM might get damaged when it flips out with extra force.
Unlocked retaining clip
