www.austin-hughes.com UM-ICM-02-Q215V1 P.1
Package Content
Installation
- 1U rackmount fan tray x 1 pc
- Temp. sensor x 1 pc
- 6 ft power cord x 1 pc
- Rear mounting bracket x 1 pair
* Bracket for MRF-1.6 / 9 & RF-1.6 / 9 only
* M6 screws for fi xing are not included
MRF-1.3 / RF-1.3
MRF-1.6 / RF-1.6
MRF-1.9 / RF-1.9
M6 screws
M6 screws
M6 screws
Rear mounting
brackets
Rear mounting
brackets
< 1.1 > 1U Fan Tray
< Part I > Installation
