Replacement, removal or addition for remote FAN unit
3. How to move out a remote fan unit ( without a replacement ) ?
Step 1
- Prepare an appropriate length Cat. 5 / 6 cable.
Step 2 - Click Disable monitoring in
fan unit.
Step 3
- Use the Cat. 5 / 6 cable to bridge over the removed remote fan unit to minimize
log / data loss.
Step 4
- Power off & remove the fan unit from connection.
If the removed remote fan unit NOT in the last level, you MUST reconfi gure and reset the
level for the affected remote fan unit(s) which next to the removed remote fan unit.
Ignore step 1 & 3 if the removed fan unit is in the last level.
4. How to add an extra remote fan unit to an existing fan unit group ?
Step 1 - Prepare a new remote fan unit and set the remote fan unit level accordingly.
( Please refer to user manual < 2.5 > for the fan unit level setting )
Step 2 - Prepare an appropriate length Cat. 5 / 6 cable.
Step 3
- Click Set maintenance in
next to the added remote fan unit.
Step 4
- Install, connect and power on the new remote fan unit.
Step 5
- Reconfi gure & reset the level for the affected remote fan unit(s) which next to the
added remote fan unit.
Step 6 - Click Remove maintenance in
Step 7 - Click Search in page to search the new installed remote fan unit.
Step 8
- Confi gure the new remote fan unit in
such as Rack, Position, Alarm Temp...
Ignore step 3, 5 & 6 if the added remote fan unit is in the last level.
< Part IX > Troubleshooting
