< 2.4 > Remote Fan Unit Specifi cation Table
Remote Fan
Model RF-1.3 / 1.6 / 1.9 RF-33.9
No. of Fan 3 / 6 / 9 9
Mounting 1U Door mount
CFM Level Normal / High / Max.
Individual Fan ON / OFF Yes
Individual Fan CFM 108 CFM
Unit CFM ( Approximately ) 324 / 648 / 972 CFM 972 CFM
IP Remote Access Not available, must be via Master IP fan on the 1st level
Daisy Chain Level 2nd to 16th level
MTBF 50,000 hrs
Temperature
Sensor
Temperature Port 1 x temperature sensor port ( sensor bundled )
Measurement Range 0 to 99.9°C
Measurement Accuracy +/- 1.5%
Temperature Alarm Yes
Power
Input 100V or 240V AC at 50 or 60Hz via IEC type cord
Consumption 20W / 40W / 60W 60W
Environmental
Conditions
Operating 0 to 50°C
Storage -5 to 60°C
Relative Humidity 90%, non-condensing
Shock 50G peak acceleration ( 11ms, half-sine wave )
Vibration 58~100Hz / 0.98G ( 11ms / cycle )
Dimensions
Model Product Dimension Packing Dimension
RF-1.3 480 x 298.3 x 43.5 mm
18.9 x 11.7 x 1.71 inch
380 x 535 x 120 mm
15 x 21.1 x 4.7 inch
RF-1.6 480 x 458.3 x 43.5 mm
18.9 x 18 x 1.71 inch
550 x 550 x 120 mm
21.7 x 21.7 x 4.7 inch
RF-1.9 480 x 623.3 x 43.5 mm
18.9 x 24.5 x 1.71 inch
550 x 730 x 120 mm
21.7 x 28.7 x 4.7 inch
RF-33.9 195 x 42.9 x 1466 mm
7.7 x 1.7 x 57.7 inch
263 x 106 x 1650 mm
10.4 x 4.2 x 65.0 inch
Weight
Model
Net Weight Gross Weight
RF-1.3 4 kgs / 8.8 lbs 5 kgs / 11 lbs
RF-1.6 6.8 kgs / 15 lbs 8 kgs / 17.6 lbs
RF-1.9 9 kgs / 19.8 lbs 11 kgs / 24.2 lbs
RF-33.9 5 kgs / 11 lbs 7.4 kgs / 16.3 lbs
Regulatory FCC & CE
Environmental RoHS2 & REACH compliant
