User's Guide 39
Front Panel Set-up Menu
FM 4602 and FM 4603 models only
The Set-up menu is a list of printer features that affect the basic operation of the printer.
These are functions that can not normally be selected using software commands. Value
settings that are changed using the keypad are stored into E2PROM and are retained when
power is cycled. Value settings that are changed using software commands are temporary
changes and are not retained when power is cycled.
LCD and Button functionality in Set-up mode
Normal Mode
Buttons Function
PAUSE +
CANCEL Enters into set-up mode.
If in set-up mode, pressing these two keys will exit Set-up
mode and return to normal mode.
Setup Mode
FEED Pressing this button will scroll to the
next value of the
displayed feature.
PAUSE Pressing this button will scroll to the
next Feature.
CANCEL Pressing this key will select the displayed value. It will also
save that value into non-volatile (E2PROM) memory.
LCD Displayed Information
Below is an example of a typical displayed Feature.
B A S E S P E E D ( I P S )
0 0 0 *
Feature name: BASE SPEED (IPS)
Feature Value: 000
Stored indicator: *
