User's Guide 37
LCD Display (FM4602 and 4603 models only)
For the model FM4602/FM4603 the front panel is equipped with a 2 row by 16 character
LCD display.
The basic function of the display is:
-
Display the printer status
-
Display the printer settings
-
Display's prompts requesting input data from a keyboard or barcode reader.
-
Standard Printer
After power on the following message is displayed on the LCD
READY (203,PPLA)
The first parameter is either 203 or 300. It stands for the printer's resolution.
FM4602 will display 203
FM4603 will display 300
The second parameter indicates the emulation (printer language), PPLA or PPLB.
With Keyboard Option installed
If a keyboard is plugged in, the following message is displayed on the LCD
READY (203,PPLA)
